Histological and biochemical effects of Cinnamomum cassia nanoparticles in kidneys of diabetic Sprague-Dawley rats

  • Koffi Kouame Discipline of Clinical Anatomy, School of Laboratory Medicine and Medical Sciences, University of KwaZulu-Natal, Durban, South Africa https://orcid.org/0000-0001-6761-0178
  • Aniekan Imo Peter Discipline of Clinical Anatomy, School of Laboratory Medicine and Medical Sciences, University of KwaZulu-Natal, Durban, South Africa
  • Edidiong Nnamso Akang Discipline of Clinical Anatomy, School of Laboratory Medicine and Medical Sciences, University of KwaZulu-Natal, Durban, South Africa; Department of Anatomy, College of Medicine, University of Lagos, Idi-Araba, Lagos, Nigeria
  • Roshila Moodley School of Chemistry and Physics, University of KwaZulu-Natal, Westville Campus, Durban, South Africa https://orcid.org/0000-0001-7296-0519
  • Edwin Coleridge Naidu Discipline of Clinical Anatomy, School of Laboratory Medicine and Medical Sciences, University of KwaZulu-Natal, Durban, South Africa
  • Onyemaechi Okpara Azu Discipline of Clinical Anatomy, School of Laboratory Medicine and Medical Sciences, University of KwaZulu-Natal, Durban, South Africa; Department of Anatomy, School of Medicine, University of Namibia, Windhoek, Namibia https://orcid.org/0000-0003-0916-7184
Keywords: Cinnamomum cassia, silver nanoparticles, diabetes, histomorphology

Abstract

This study investigated the antidiabetic activity of Cinnamomum cassia (C. cassia, Cc) silver nanoparticles (CcAgNPS) and effects of C. cassia on the kidneys of rats with induced type 2 diabetes. Twenty-four Sprague-Dawley rats weighing 250 ± 20 g were induced with diabetes by intraperitoneal injection of streptozotocin (STZ, 60 mg/kg). Animals were randomly assigned to one of four groups (n = 6) and treated for eight weeks with normal saline (control, group A), 5 mg/kg of CcAgNPs (group B), 10 mg/kg of CcAgNPs (group C), or 200 mg/kg of Cc (group D). Body weight and fasting blood glucose (FBG) was measured weekly and fortnightly, respectively. At the end of experiments, animals were euthanized, blood and kidney tissue samples were collected for biochemistry (oxidative stress markers and renal function parameters) and kidneys were harvested for histology (PAS and HE staining). Body weight was significantly higher in group B and C vs. control (p < 0.05), while no significant differences were observed in the kidney-to-body weight ratio between groups. FBG, glutathione, malondialdehyde, alanine aminotransferase, aspartate aminotransferase, serum urea and creatinine were significantly lower in group B, C and/or D vs. control (all p < 0.05). In group A, severe distortion of the glomerular network was observed, marked by the loss of capsular integrity, thickened basement membrane, tubular cells with pyknotic nuclei, vacuolization, and interstitial space with infiltrations. These adverse effects were mitigated by 5 mg/kg and 10 mg/kg of CcAgNPs. Our study confirms structural and functional damage to kidneys caused by diabetes. CcAgNPs have a regenerative potential in diabetes-induced kidney damage and may be used as an antidiabetic agent.

Downloads

Download data is not yet available.

References

Organization WH. Global report on diabetes: World Health Organization; 2016.

Subramoniam A. Plants with anti-diabetes mellitus properties: CRC Press; 2016.

Satyanarayana T, Katyayani B, Latha HE, Mathews AA, Chinna EM. Hypoglycemic and antihyperglycemic effect of alcoholic extract of Euphorbia leucophylla and its fractions in normal and in alloxan induced diabetic rats. Pharmacognosy Magazine. 2006;2(8):244.

Zhou X, Wang B, Zhu L, Hao S. A novel improved therapy strategy for diabetic nephropathy: targeting AGEs. Organogenesis. 2012;8(1):18-21.

Mieszawska AJ, Mulder WJ, Fayad ZA, Cormode DP. Multifunctional gold nanoparticles for diagnosis and therapy of disease. Molecular pharmaceutics. 2013;10(3):831-47.

Lee H-S. Inhibitory activity of Cinnamomum cassia bark-derived component against rat lens aldose reductase. J Pharm Pharm Sci. 2002;5(3):226-30.

Sulaiman F, Akanji M, Oloyede H, Sulaiman A, Olatunde A, Joel E, et al. Oral Exposure to Silver/Gold Nanoparticles: Status of Rat Lipid Profile, Serum Metabolites and Tissue Morphology. Journal of Medical Sciences. 2015;15(2):71.

Zhang X-F, Choi Y-J, Han JW, Kim E, Park JH, Gurunathan S, et al. Differential nanoreprotoxicity of silver nanoparticles in male somatic cells and spermatogonial stem cells. International journal of nanomedicine. 2015;10:1335.

Panyam J, Labhasetwar V. Biodegradable nanoparticles for drug and gene delivery to cells and tissue. Advanced drug delivery reviews. 2003;55(3):329-47.

Chen X, Schluesener H. Nanosilver: a nanoproduct in medical application. Toxicology letters. 2008;176(1):1-12.

Awazu K, Fujimaki M, Rockstuhl C, Tominaga J, Murakami H, Ohki Y, et al. A plasmonic photocatalyst consisting of silver nanoparticles embedded in titanium dioxide. Journal of the American Chemical Society. 2008;130(5):1676-80.

Ansari S, Farha Islam M. Influence of nanotechnology on herbal drugs: A Review. Journal of advanced pharmaceutical technology & research. 2012;3(3):142.

Ranasinghe P, Pigera S, Premakumara GS, Galappaththy P, Constantine GR, Katulanda P. Medicinal properties of ‘true’cinnamon (Cinnamomum zeylanicum): a systematic review. BMC complementary and alternative medicine. 2013;13(1):275.

Bandara T, Uluwaduge I, Jansz E. Bioactivity of cinnamon with special emphasis on diabetes mellitus: a review. International journal of food sciences and nutrition. 2012;63(3):380-6.

Malviya N, Jain S, Malviya S. Antidiabetic potential of medicinal plants. Acta Pol Pharm. 2010;67(2):113-8.

Shankar T, Karthiga P, Swarnalatha K, Rajkumar K. Green synthesis of silver nanoparticles using Capsicum frutescence and its intensified activity against E. coli. Resource-Efficient Technologies. 2017.

Daisy P, Saipriya K. Biochemical analysis of Cassia fistula aqueous extract and phytochemically synthesized gold nanoparticles as hypoglycemic treatment for diabetes mellitus. International journal of nanomedicine. 2012;7:1189.

BarathManiKanth S, Kalishwaralal K, Sriram M, Pandian SRK, Youn H-s, Eom S, et al. Anti-oxidant effect of gold nanoparticles restrains hyperglycemic conditions in diabetic mice. Journal of nanobiotechnology. 2010;8(1):16.

Latendresse JR, Warbrittion AR, Jonassen H, Creasy DM. Fixation of testes and eyes using a modified Davidson's fluid: comparison with Bouin's fluid and conventional Davidson's fluid. Toxicologic pathology. 2002;30(4):524-33.

Gundersen H, Jensen E. The efficiency of systematic sampling in stereology and its prediction. Journal of microscopy. 1987;147(3):229-63.

Kent Christensen A, Peacock KC. Increase in Leydig cell number in testes of adult rats treated chronically with an excess of human chorionic gonadotropin. Biology of reproduction. 1980;22(2):383-91.

Skov K, Mulvany M, Korsgaard N. Morphology of renal afferent arterioles in spontaneously hypertensive rats. Hypertension. 1992;20(6):821-7.

Ogedengbe OO, Jegede AI, Onanuga IO, Offor U, Naidu EC, Peter AI, et al. Coconut Oil Extract Mitigates Testicular Injury Following Adjuvant Treatment with Antiretroviral Drugs. Toxicological research. 2016;32(4):317.

Abou-Seif MA, Youssef A-A. Evaluation of some biochemical changes in diabetic patients. Clinica Chimica Acta. 2004;346(2):161-70.

Arkkila PE, Koskinen PJ, Kantola IM, Rönnemaa T, Seppänen E, Viikari JS. Diabetic complications are associated with liver enzyme activities in people with type 1 diabetes. Diabetes Research and Clinical Practice. 2001;52(2):113-8.

Ramesh B, Viswanathan P, Pugalendi KV. Protective effect of Umbelliferone on membranous fatty acid composition in streptozotocin-induced diabetic rats. European journal of pharmacology. 2007;566(1):231-9.

Budin SB, Ismail H, Chong PL. Psidium guajava fruit peel extract reduces oxidative stress of pancreas in streptozotocin-induced diabetic rats. Sains Malaysiana. 2013;42(6):707-13.

Shirwaikar A, Rajendran K, Barik R. Effect of aqueous bark extract of Garuga pinnata Roxb. in streptozotocin-nicotinamide induced type-II diabetes mellitus. Journal of ethnopharmacology. 2006;107(2):285-90.

Hakim ZS, Patel BK, Goyal RK. Effects of chronic ramipril treatment in streptozotocin-induced diabetic rats. Indian journal of physiology and pharmacology. 1997;41:353-60.

Al-Quraishy S, Dkhil MA, Moneim AEA. Anti-hyperglycemic activity of selenium nanoparticles in streptozotocin-induced diabetic rats. International journal of nanomedicine. 2015;10:6741.

Whitton PD, Hems DA. Glycogen synthesis in the perfused liver of streptozotocin-diabetic rats. Biochemical Journal. 1975;150(2):153-65.

Hassan Z, Ahmad MAAM, Naidu SR, Kumar G, Umachigi SP.

Hypoglycaemic effects of aqueous extract of Gynura procumbens. Pharmacologyonline. 2008;1:30-50.

Hassan Z, Yam MF, Ahmad M, Yusof APM. Antidiabetic properties and mechanism of action of Gynura procumbens water extract in streptozotocin-induced diabetic rats. Molecules. 2010;15(12):9008-23.

Zafar M, Naqvi S, Ahmed M, Kaimkhani ZA. Altered kidney morphology and enzymes in streptozotocin induced diabetic rats. Int J Morphol. 2009;27(3):783-90.

Malatiali S, Francis I, Barac-Nieto M. Phlorizin prevents glomerular hyperfiltration but not hypertrophy in diabetic rats. Experimental diabetes research. 2008;2008.

Adeyemi OS, Sulaiman FA. Biochemical and morphological changes in Trypanosoma brucei brucei-infected rats treated with homidium chloride and diminazene aceturate. Journal of basic and clinical physiology and pharmacology. 2012;23(4):179-83.

Adeyemi OS, Akanji MA. Psidium guajava leaf extract: effects on rat serum homeostasis and tissue morphology. Comparative Clinical Pathology. 2012;21(4):401-7.

Nabi SA, Kasetti RB, Sirasanagandla S, Tilak TK, Kumar MVJ, Rao CA. Antidiabetic and antihyperlipidemic activity of Piper longum root aqueous extract in STZ induced diabetic rats. BMC complementary and alternative medicine. 2013;13(1):37.

Li B, Wang Z, Fang J-J, Xu C-Y, Chen W-X. Evaluation of prognostic markers in severe drug-induced liver disease. World journal of gastroenterology: WJG. 2007;13(4):628.

Concepción NM, Pilar MM, Martin A, Jimenez J, Pilar UM. Free radical scavenger and antihepatotoxic activity of Rosmarinus tomentosus. Planta medica. 1993;59(4):312-4.

Adeyemi O, Sulaiman F, Akanji M, Oloyede H, Sulaiman A, Olatunde A, et al. Biochemical and morphological changes in rats exposed to platinum nanoparticles. Comparative Clinical Pathology. 2016;25(4):855-64.

Wohaieb SA, Godin DV. Alterations in free radical tissue-defense mechanisms in streptozocin-induced diabetes in rat: effects of insulin treatment. Diabetes. 1987;36(9):1014-8.

Tang K, Zhan J-C, Yang H-R, Huang W-D. Changes of resveratrol and antioxidant enzymes during UV-induced plant defense response in peanut seedlings. Journal of plant physiology. 2010;167(2):95-102.

Marles RJ, Farnsworth NR. Antidiabetic plants and their active constituents. Phytomedicine. 1995;2(2):137-89.

Baynes JW. Role of oxidative stress in development of complications in diabetes. Diabetes. 1991;40(4):405-12.

King GL, Loeken MR. Hyperglycemia-induced oxidative stress in diabetic complications. Histochemistry and cell biology. 2004;122(4):333-8.

Kawahito S, Kitahata H, Oshita S. Problems associated with glucose toxicity: role of hyperglycemia-induced oxidative stress. World journal of gastroenterology: WJG. 2009;15(33):4137.

Baynes JW, Thorpe R. Perspectives in Diabetes Role of Oxidative Stress in Diabetic Complications. Diabetes. 1999;48.

Yakimovich N, Ezhevskii A, Guseinov D, Smirnova L, Gracheva T, Klychkov K. Antioxidant properties of gold nanoparticles studied by ESR spectroscopy. Russian Chemical Bulletin. 2008;57(3):520-3.

Shukla R, Bansal V, Chaudhary M, Basu A, Bhonde RR, Sastry M. Biocompatibility of gold nanoparticles and their endocytotic fate inside the cellular compartment: a microscopic overview. Langmuir. 2005;21(23):10644-54.

Histological and biochemical effects of Cinnamomum cassia nanoparticles in kidneys of diabetic Sprague-Dawley rats
Published
2019-05-20
How to Cite
1.
Kouame K, Peter AI, Akang EN, Moodley R, Naidu EC, Azu OO. Histological and biochemical effects of Cinnamomum cassia nanoparticles in kidneys of diabetic Sprague-Dawley rats. Bosn J of Basic Med Sci [Internet]. 2019May20 [cited 2021Apr.15];19(2):138-45. Available from: https://bjbms.org/ojs/index.php/bjbms/article/view/3481
Section
Biochemistry

INTRODUCTION

Diabetes is no longer a disease of predominantly rich nations and the prevalence of diabetes is steadily increasing in the middle-income countries, including African countries [1]. Despite the introduction of various antidiabetic and hypoglycemic agents, diabetes and associated secondary complications continue to be a major health problem worldwide [2]. Antidiabetic drugs currently in use do not completely control blood glucose levels, moreover, they cause side effects and insufficient response after prolonged use. Therefore, efforts are being made to find new medicines and therapeutic interventions to treat this debilitating condition [2]. Satyanarayan et al. [3] emphasized the need for alternative therapies in patients with diabetes, with a special focus on different indigenous plants. Compared to conventional drug formulations, nanotechnology-based drug carriers are more advantageous for medical use [4] and may be used for the treatment of various diseases.

Nanobiotechnology is a rapidly developing discipline at the intersection of nanotechnology and biology, utilized for the exploration and transformation of biological systems and pharmaceutics. Targeting of nanocarriers can be improved through conjugation with various active bio-ligands such as biotin [4]. Moreover, core-shell and multi-layered nanoparticles can be loaded with several drugs and modified to enable controlled drug release. The integration of such nanocarriers in the treatment of diabetic nephropathy appears to be very promising [4].

Over the past few years, the success with the so-called green synthesis of biocompatible silver nanoparticles (AgNPs) has gained much attention for its application in biomedical sciences [5]. NPs are particles with a diameter of 100 nm or less that possess unique physical, chemical and biological properties, which make them potent diagnostic and therapeutic tools. Silver (Ag) is the metal of choice for the application of NPs in biology and medicine. AgNPs have been used as anticancer, antiangiogenic, and antibacterial agents [6-8]. Moreover, they can be used to treat diseases that require a sustained release of a drug at several anatomical sites [9]. Due to the ultra-small size of AgNPs (1–100 nm), they exhibit unique physical, chemical, magnetic and optical properties [10,11]. Furthermore, they enhance solubility, bioavailability, pharmacological activity and stability of drugs, and protect from their toxicity [12]. Incorporation of herbal extracts into novel formulation systems such as nanosized drug delivery systems has captured the attention of major pharmaceutical corporations, due to the ability of those systems to overcome multiple dosage and lower absorption as major problems [12]. Natural products such as medicinal plants have, therefore, been a very good source of green NPs.

Cinnamomum cassia (C. cassia) of the plant family Lauraceae, also known as Chinese cassia or Chinese cinnamon, is an evergreen tree originating from southern China and widely cultivated in southern and eastern Asia. Nowadays, C. cassia is also found in Southern Africa. C. cassia extracts have shown to have antidiabetic effects in vitro [6]. In addition, it has been reported that C. cassia lowers blood glucose, blood pressure and serum cholesterol levels, exerts antioxidant and free radical scavenging activity, and has hepatoprotective effects in vivo [13,14]. However, in contrast to other medicinal plants that have been used as antidiuretic and antihyperlipidemic remedies [15], there is a lack of data on C. cassia effects on the kidneys in animal models with diabetes. In this study, we investigated the antidiabetic activity of C. cassia silver nanoparticles (CcAgNPs) and effects of C. cassia on the kidneys of rats with induced type 2 diabetes.

MATERIALS AND METHODS

Collection of plant material

Pure C. cassia powder was obtained from Warren Chem Specialities (Pty), Cape Town (Reference 492733) and silver nitrate (AgNO3) was obtained from Capital Laboratory (Pty), KwaZulu-Natal.

Preparation of aqueous plants extract

The aqueous extract of C. cassia was prepared by adding a fine powder of the plant (10 g) to 300 mL of double-distilled water, which was allowed to boil for 10 minutes [16]. The resulting mixture was filtered and stored in a refrigerator at 4°C until analyzed.

Synthesis of Cinnamomum cassia silver nanoparticles (CcAgNPs)

An aqueous solution of AgNO3 was dissolved in 250 mL Erlenmeyer flasks and added dropwise to 100 mL of the plant extract while stirring and heated at 45°C. This solution was stirred constantly at room temperature for 120 minutes, using a magnetic stirrer. A color change from light brown to dark brown indicated the formation of AgNPs.

Structural analysis of CcAgNPs

The CcAgNPs solution was centrifuged in an Eppendorf Centrifuge (Model: 5804/5804 R, USA). The treated solutions were transferred separately into Eppendorf tubes that were pre-weighed and subjected to purification for 2 hours at 5000 rpm and 4°C.

The bioreduction of Ag1 to Ag0 was evaluated using a SHIMADZU UV-2600 UV-Vis spectrophotometer (Shimadzu, Tokyo, Japan), at a range of 120–900 nm and with a resolution of 1 nm. UV-Vis analysis was performed by taking a baseline measurement with the solvent (distilled water) at different wavelengths from 190 nm to 900 nm, at room temperature and pH 3.96 [17]. An aqueous component of C. cassia was sampled. The component was scanned over 190 nm to 900 nm wavelength range.

To evaluate the bioreduction and capping functional groups of AgNPs, infrared spectra of the extracts and their corresponding biosynthesized AgNPs were obtained on a Fourier transform infrared (FTIR) spectrophotometer with universal attenuated total reflectance (ATR) sampling accessory (Perkin Elmer Spectrum 100, USA) [17]. The size and morphology of AgNPs were examined using transmission electron microscopy (TEM). Powdered AgNPs were mixed with the pellet and the analysis was immediately carried out using the Perkin Elmer-Spectrum 100 (Perkin Elmer) [17].

Transmission electron microscopy (TEM) was also used to obtain selected area electron diffraction (SAED) patterns of AgNPs to evaluate their crystallinity. For TEM measurements, solutions of synthesized AgNPs were sonicated using a sonication bath (Soniclean, England) and evenly dispersed AgNPs were coated onto carbon-coated TEM grids and placed under a lamp to evaporate the solvent before analysis.

Animal handling and ethics approval

Twenty-four pathogen-free, male, Sprague-Dawley rats weighing 250 ± 20 g were selected for the experiments; they were kept and maintained under laboratory conditions at a temperature of 21.5°C to 2.2°C, humidity (60 ± 1%), and 12 hour light/dark cycle. They were allowed free access to food (standard pellets) and water, and were fed ad libitum.

Animals were allowed to acclimatize in their respective cages for seven days prior to the commencement of experiments. The institutional Ethics Committee of the University of KwaZulu-Natal approved the experimental protocols and procedures used in this study (Ethics references number AREC/074/016 D).

Induction of type 2 diabetes

Hyperglycemia was induced by injecting nicotinamide [100 mg/kg of body weight] (Sigma Aldrich, South Africa) and streptozotocin (STZ, 60 mg/kg, intraperitoneal injection [I.P]). Nicotinamide was administered 15 minutes before STZ that was dissolved in phosphate buffer citrate at pH 4.5 immediately before use [18].

Animals were then kept under observation for confirmation of diabetes induction. Blood glucose was tested and monitored on days 0, 7, 14, 28, 42, and 56. The animals were tested using Accu-chek Active 50 (Roche) blood glucose test strips, purchased from Dis-Chem, South Africa. Blood was collected from the tail vein of the rats at 10 am daily. The animals with a fasting blood glucose (FBG) level >9 mmol/L were considered diabetic.

Experimental design

Twenty-four STZ-induced diabetic Sprague-Dawley rats were randomly assigned to four groups (six animals per group). In control group A, rats received normal saline (1 mL) orally once per day. Group B rats were orally administered with CcAgNPs at low dose (5 mg/kg), once per day [7]. Group C rats were orally administered with CcAgNPs at high dose (10 mg/kg), once per day [7]. Group D rats were administered with C. cassia plant extract at 200 mg/kg. CcAgNPs and C. cassia plant extract were dissolved in normal saline and administered orally once daily at 10 am for 56 consecutive days, using a rat gavage needle [17]. FBG was measured on days 0, 14, 28, 42 and 56. Body weight was recorded every week between 8:00 am and 10:00 am using an electronic balance (Zeiss, West Germany (Pty) Ltd; 0.000 g calibration). At the end of the experiment, all rats were euthanized with an overdose of Halothane anesthesia. Blood was immediately withdrawn via cardiac puncture and stored in 10 ml EDTA heparinized tubes. After that, it was centrifuged at 3000 rpm for 10 minutes and serum was collected using Eppendorf tubes and stored at -80°C in a deep freezer.

After laparotomy, organs were harvested for histology. Kidneys were immediately washed with phosphate buffer solution (PBS) to remove blood and then dissected. Blood and kidney tissue samples were used for biochemistry (oxidative stress biomarkers: glutathione [GSH], malondialdehyde [MDA], alanine aminotransferase [ALT], aspartate aminotransferase [AST], and albumin [ALB]; renal function parameters: serum urea, creatinine, and uric acid). In addition, the weight of the kidneys was recorded.

Measurement of MDA levels in rat kidney tissue

Kidney tissue was homogenized in 0.2 M sodium phosphate buffer (pH 7.8) and then centrifuged for 15 minutes at 12000 rpm to separate the supernatant from the tissue extract, which is done under high speed. The supernatant was then collected and used for the measurement of lipid peroxidation. The procedure was carefully performed according to a previous method with slight modifications [19]. This method indicated the complex formed between MDA and thiobarbituric acid (TBA). Two hundred microliters of MDA standard series (0, 7.5, 15, 22.5, and 30 µL) was added to a Pyrex screw-capped test tube containing the assay mixture of 200 µL of 8.1% sodium dodecylsulfate (SDS), 750 µL of 20% acetic acid (pH 3.5), 2 mL of 0.25% TBA, and 850 µL of distilled water. The mixture was heated at 95°C for 60 minutes in a sand bath, cooled down to room temperature, and the absorbance was read at 532 nm using the spectrophotometer Synergy HTX multi-mode reader (Vacutec, USA). The concentration of TBA reactive substances (TBARS) in the samples was extrapolated from the MDA standard curve.

Measurement of GSH levels in rat kidney tissue

Glutathione concentration was assessed in rat renal tissue. The sample was first precipitated with 10% trichloroacetic acid (TCA) and then centrifuged at 2000 rpm for 10 minutes at 25°C. This technique was not used to separate the supernatant from the tissue extract but to separate the deproteinized supernatant from the extracted sample (tissue extract). The low centrifugation speed was also used to separate protein sediment according to the following steps: precipitated sample was inserted into the centrifuge, centrifuged, and as a result a supernatant and precipitate were obtained. This reaction mixture contained 100 µL of supernatant, 50 µL of 0.5 mM 5,5’-dithiobis-2-nitrobenzoic acid (DTNB) and 150 µL of 0.2 M sodium phosphate buffer (pH 7.8). After 15 minutes incubation at 25°C, the absorbance was measured at 412 nm using a spectrophotometer (Synergy HTX multi-mode reader, VACUTEC, USA). GSH concentration was extrapolated from a standard GSH curve.

Histopathological examination of rat kidney tissues

Kidneys were washed in saline and fixed in 10% neutral buffered formalin for 24 hours. The samples were transferred to 70% ethanol solution [20]. Ascending grades of alcohol were then used to dehydrate the samples and xylene was used as a clearing agent. The samples were immersed in molten paraffin wax at 58°C to 62°C. The prepared blocks were cut into slices of 5 µm) using a microtome (Microtome HM 315, Walldorf, Germany) and stained with hematoxylin and eosin (H&E) stain.

Additionally, the periodic acid-Schiff (PAS) staining technique was used to detect the presence of polysaccharides (e.g., glycogen) and mucosubstances (e.g., glycoproteins, glycolipids, and mucins) in rat kidney tissues. The PAS technique is most commonly used to evaluate the thickness of glomerular basement membrane (GBM) in renal disease [21]. The sections were viewed and photographed using an Olympus light microscope (Olympus BX, Tokyo, Japan) with an attached camera (Olympus E-330, Olympus Optical Co. Ltd., Tokyo, Japan).

Statistical analysis

All results are presented as the mean ± standard error of the mean (SE). One-way analysis of variance (ANOVA) followed by Turkey’s post-hoc test was performed using GraphPad Prism version 5.00 for Windows (GraphPad Software, La Jolla, California, USA). Comparisons with p < 0.05 were considered statistically significant.

RESULTS

Synthesis of CcAgNPs

The aqueous solution of biosynthesized AgNPs from C. cassia powder showed a dark brown color indicating the formation of AgNPs (150 mg).

Effects of CcAgNPs on rat body and kidney weight

The oral treatment of diabetic rats with a low (5 mg/kg) and high (10 mg/kg) dose of CcAgNPs significantly increased the body weight of experimental animals compared to saline-treated diabetic controls (p < 0.05). In addition, the kidney-to-body weight ratio was not significantly different between groups [p > 0.05] (Table 1).

TABLE 1: Effects of Cinnamomum cassia silver nanoparticles (CcAgNPs) on body weight of streptozotocin-induced diabetic rats

Effects of CcAgNPs on FBG levels

A significant reduction in FBG levels was observed in group B (5 mg/kg CcAgNPs), group C (10 mg/kg CcAgNPs), and group D (200 mg/kg C. cassia extract) of diabetic rats compared to diabetic control rats treated with saline [p < 0.05] (Figure 1).

FIGURE 1: Comparison of FBG levels (mmol/L) between different groups of streptozotocin-induced diabetic rats. A significant reduction in FBG levels was observed in group B (5 mg/kg CcAgNPs), group C (10 mg/kg CcAgNPs), and group D (200 mg/kg C. cassia extract) of diabetic rats compared to diabetic rats treated with saline (group A) [*p < 0.05]. FBG: Fasting blood glucose; CcAgNPs: Cinnamomum cassia silver nanoparticles.

Effects of CcAgNPs on renal function parameters

Diabetic rats treated with 5 mg/kg (group B) and 10 mg/kg (group C) doses of CcAgNPs showed significantly reduced levels of serum urea and creatinine compared to saline-treated diabetic rats (p < 0.05). In addition, this effect of CcAgNPs on the renal function parameters of diabetic rats was higher in group B compared to group C (Figure 2).

FIGURE 2: Comparison of serum urea and creatinine levels (mg/dL) between different groups of streptozotocin-induced diabetic rats. Diabetic rats treated with 5 mg/kg (group B) and 10 mg/kg (group C) doses of CcAgNPs showed significantly reduced levels of serum urea and creatinine compared to saline-treated diabetic rats (group A) [*p < 0.05]. CcAgNPs: Cinnamomum cassia silver nanoparticles.

Effects of CcAgNPs on the histology of kidneys in diabetic rats

H&E-stained kidney sections of diabetic rats in control group showed a severe distortion of the glomerular architecture, with atrophic and necrotic changes, pyknotic nuclei as well as infiltrations of mesangial spaces and interstitium. Many of the proximal and distal convoluted tubules showed hypertrophic cells and vacuolization (Figure 3A). H&E-stained sections of diabetic rats in group B (5 mg/kg CcAgNPs) showed moderate degenerative changes in the glomeruli. The mesangium and interstitium were essentially normal with cellular components (Figure 3B). In group C (10 mg/kg CcAgNPs), the kidney sections (Figure 3C) showed glomeruli with Bowman’s space and capillary tufts, which appeared normal compared to controls. The kidney sections of diabetic rats in group D (200 mg/kg C. cassia extract) looked normal with clearly visible glomeruli, basement membrane of the capsular wall, and mesangial tissue (Figure 3D). The interstitium appeared normal and with no infiltrations.

FIGURE 3: Hematoxylin and eosin (H&E)-stained kidney sections of streptozotocin-induced diabetic rats in different groups. A) In control group A (saline), the sections showed a severe distortion of the glomerular architecture, with atrophic and necrotic changes, pyknotic nuclei as well as infiltrations of mesangial spaces and interstitium. Many of the proximal and distal convoluted tubules showed hypertrophic cells and vacuolization. B) In group B (5 mg/kg CcAgNPs), there were moderate degenerative changes in the glomeruli. The mesangium and interstitium were essentially normal with cellular components. C) In group C (10 mg/kg CcAgNPs), the kidney sections showed glomeruli with Bowman’s space and capillary tufts, which appeared normal compared to controls. D) The kidney sections of diabetic rats in group D (200 mg/kg C. cassia extract) looked normal with clearly visible glomeruli, basement membrane of the capsular wall, and mesangial tissue. G: Glomerulus; DCT: Distal convoluted tubules; PCT: Proximal convoluted tubules; White arrow: Bowman’s space; Black arrow: Mesangial cells; Green arrow: Parietal layer; CcAgNPs: Cinnamomum cassia silver nanoparticles.

PAS-stained kidney sections of diabetic control rats (group A) showed glomerular distortions and ruptured capsular wall (stained purple), thickened basement membranes, and hypocellularity in the interstitial components. In group B and C, the PAS-staining intensity for glycogens was stronger; moreover the capsular walls of the glomeruli were evident in group B. The mesangial tissues were clearly delineated and interstitial tissue did not indicate any abnormalities. The kidney sections of group D (200 mg/kg C. cassia extract) showed PAS-positive glomerular capsular basement layers stained purple, indicating a normal glomerular tuft/capillary meshwork. The proximal and distal convoluted tubular cells with no abnormalities and purple-stained (glycogen) membranes of tubules were clearly visible (Figure 4A-D).

FIGURE 4: Periodic acid-Schiff (PAS)-stained kidney sections of streptozotocin-induced diabetic rats in different groups. A) The sections in control group A (saline) showed glomerular distortions and ruptured capsular wall (stained purple), thickened basement membranes, and hypocellularity in the interstitial components. B-C) In group B (5 mg/kg CcAgNPs) and C (10 mg/kg CcAgNPs), the PAS-staining intensity for glycogens was stronger; moreover the capsular walls of the glomeruli were evident in group B. The mesangial tissues were clearly delineated and interstitial tissue did not indicate any abnormalities. D) The kidney sections of group D (200 mg/kg C. cassia extract) showed PAS-positive glomerular capsular basement layers stained purple, indicating a normal glomerular tuft/capillary meshwork. The proximal and distal convoluted tubular cells with no abnormalities and purple-stained (glycogen) membranes of tubules were clearly visible. Note the thickening of basement membranes in A part. G: Glomerulus; DCT: Distal convoluted tubules; PCT: Proximal convoluted tubules; White arrow: Bowman’s space; Black arrow: Mesangial cells; Green arrow: Parietal layer; CcAgNPs: Cinnamomum cassia silver nanoparticles.

Effects of CcAgNPs on oxidative stress biomarkers

GSH levels were significantly lower in groups B, C, and D compared to control (p < 0.05). MDA and AST levels were significantly lower in groups B and C compared to control (p < 0.05). ALT levels were significantly lower in group B compared to control (p < 0.05). On the other hand, no significant differences were observed in ALB levels between experimental groups and control (Table 2).

TABLE 2: Effects of Cinnamomum cassia silver nanoparticles (CcAgNPs) on oxidative stress markers in streptozotozin-induced diabetic rats

DISCUSSION

Diabetes and its vascular complications are associated with different biochemical disorders such as hyperlipidemia and oxidative stress [22]. In our study, the treatment of diabetic rats with high and low dose of CcAgNPs resulted in weight gain, probably due to changes in glucose and lipid metabolism. The body weight in STZ-induced diabetic rats was reduced partly due to the increased rate of proteolysis and lipolysis in the diabetic state, which leads to muscle wasting and consequent loss of adipose tissue [23]. An increase in body weight in rats treated with CcAgNPs might also be due to higher fluid intake and decreased urinary glucose excretion.

Previous studies have shown the ability of cinnamon to control hyperglycemia in diabetes [13]. In our study, diabetic rats treated with CcAgNPs increased their body weight by decreasing blood glucose levels. Similar findings were reported previously, which showed that oral administration of biosynthesized Cassia fistula gold nanoparticles improves body weight in rats with STZ-induced diabetes [17]. The proposed underlying mechanisms by which plant extracts control high blood glucose levels are the stimulation of pancreatic insulin secretion from β-cells in the islets of Langerhans and increased transport of blood glucose to peripheral tissues [24]. C. cassia extracts (nanoparticle conjugates) might have direct effects on residual beta cell secretion and probably increase peripheral utilization of glucose, as postulated by Hassan et al. [25]. Gynura procumbens water extract showed hypoglycemic effect by promoting glucose uptake through muscles, and C. cassia might have a similar mechanism of action. Nevertheless, in this study, we did not perform assays with pancreatic tissue of diabetic rats to confirm these assumptions.

In most of our cases, we observed lesions in the kidney sections similar to those seen in glomerulosclerosis in human patients. Zafar et al. [26] showed glomerular membrane thickening and early hypertrophy of glomeruli in the kidney sections of STZ-induced diabetic rats. Glomerular hypertrophy in diabetes represents an early event in the progression of glomerular pathology, in the absence of mesengial expansion [26,27].

Serum urea and creatinine are useful indices for evaluating the status of renal function. An increase in the level of serum urea may imply impaired renal excretion [28]. In our study, the serum levels of urea and creatinine increased in saline-treated diabetic control rats (Figure 2) but showed a concomitant decline in the groups treated with CcAgNPs, suggesting that renal dysfunction and possible kidney injury occurred in control diabetic rats due to severe hyperglycemia [29]. The observed increase in serum urea and creatinine levels in control diabetic rats was corroborated by the histomorphological changes indicative of early diabetic nephropathy, including mesangial expansion, diffuse GBM thickening and increased mesangial cellularity [29]. On the other hand, these effects were mitigated by 5 mg/kg and 10 mg/kg of CcAgNPs in group B and C, respectively.

In our study, increased ALT and AST levels indicated hepatic dysfunction due to hyperglycemia in STZ-induced diabetic rats (Table 2). ALT and AST are released when the injury involves organelles such as the mitochondria. Transaminases catalyze a transamination reaction and are vital markers of liver injury in clinical diagnostics [30]. A decrease in the level of serum urea after 56 days of administration of CcAgNPs observed in our study might be attributable to reduced amino acid degradation by the liver; moreover, this finding correlates with a decline in ALB levels in CcAgNPs-treated groups. Previously, studies showed that serum creatinine levels in animal model were significantly reduced suggesting enhanced glomerular clearance or impaired muscle metabolism [31,32].

Tissue antioxidant status is suggested to be an important factor in the development of diabetic complications [33]. Medicinal plants used to synthesize AgNPs, including C. cassia, exhibit strong antioxidant and free radical scavenging properties [34]. The antioxidant defense system is comprised of several enzymes, such as catalase and GSH, which are responsible for the maintenance of redox homeostasis and prevention of oxidative stress [35]. In hyperglycemia, MDA levels increase [18] due to increased oxidant production, which impairs the antioxidant defense system via multiple pathways [36].

Diabetes mellitus is a leading cause of kidney disease globally and the assessment of renal functional parameters remains an essential tool in the diagnosis of diabetes. In this study, in addition to urea and creatinine, we have measured serum AST, ALP and ALB levels and showed that increased ALP levels reflected renal insufficiency in saline-treated control diabetic rats, while CcAgNPs-treatment attenuated this effect.

Albuminuria is a known prognostic marker of diabetic nephropathy [37]. Although serum ALB levels in our study were lower in CcAgNPs-treated groups they were not significantly different compared to saline-treated group. The presence of albuminuria in patients with diabetes usually indicates an underlying structural renal damage, as demonstrated by histological studies [38]. While C. cassia essential oil is known to contain several active components, such as cinnamaldehyde, flavonoids and coumarins, the specific component responsible for its antidiabetic effects is yet to be identified [39].

CONCLUSION

Our study showed that C. cassia silver nanoparticles (CcAgNPs) produced using the green synthesis approach are able to attenuate the histomorphological changes following STZ-induced diabetes, possibly acting via oxidant/antioxidant pathways.
